<h3 class="m-h3--wysiwyg">外形図・製品仕様</h3><div class="m-thumbnail"><div class="m-thumbnail__img has-border" data-autoheight="item"><img alt="丸形スキットブラケット　MRTB MRTB-N " src="//content.misumi-ec.com/image/upload/t_msmwm_wyg/v1/p/jp/product/wysiwyg/110100174560/110100174560_001_20230801115851.gif" /></div></div><p><span class="m_sp1"></span>材質&nbsp;&nbsp;SS400<br /><span class="m_sp2"></span>表面処理&nbsp;&nbsp;四三酸化鉄皮膜（Fe<sub>3</sub>O<sub>4</sub>）</p><table class="m-table u-wauto" summary="丸形スキットブラケット　MRTB MRTB-N Table1"><tbody><tr><th style="text-align: center;border-Left: 0px solid;">&phi;D</th><th style="text-align: center;">（A）</th><th style="text-align: center;border-Right: 0px solid;">B</th></tr><tr><td class="coloredCell" style="text-align: center;border-Left: 0px solid;">20</td><td class="coloredCell" style="text-align: center;">67+S</td><td class="coloredCell" style="text-align: center;border-Right: 0px solid;">22.5+S</td></tr><tr><td class="coloredCell" style="text-align: center;border-Left: 0px solid;">30</td><td class="coloredCell" style="text-align: center;">77.5+S</td><td class="coloredCell" style="text-align: center;border-Right: 0px solid;">28+S</td></tr></tbody></table><h3 class="m-h3--wysiwyg">規格表</h3><table class="m-table" summary="丸形スキットブラケット　MRTB MRTB-N Table2"><colgroup><col width="12.7%" /><col width="12.9%" /><col width="12.9%" /><col width="18.7%" /><col width="11.8%" /><col width="17.4%" /><col width="13.5%" /></colgroup><tbody><tr><th rowspan="2" style="text-align: center;">e</th><th rowspan="2" style="text-align: center;">d<sub>1</sub></th><th rowspan="2" style="text-align: center;">d<sub>2</sub></th><th colspan="2" style="text-align: center;">型式</th><th colspan="2" style="text-align: center;">指定10mm単位</th></tr><tr><th style="text-align: center;">Type</th><th style="text-align: center;">D</th><th style="text-align: center;">L</th><th style="text-align: center;">S</th></tr><tr><td class="coloredCell" style="text-align: center;">26.0</td><td class="coloredCell" style="text-align: center;">21</td><td class="coloredCell" style="text-align: center;">30</td><td rowspan="2" style="text-align: center;"><span class="fontType">MRTB</span><br /><span class="fontType">MRTB-N</span></td><td style="text-align: center;"><span class="fontType">20</span></td><td rowspan="2" style="text-align: center;"><span class="fontType">100～300</span></td><td rowspan="2" style="text-align: center;"><span class="fontType">0～150</span></td></tr><tr><td class="coloredCell" style="text-align: center;">37.5</td><td class="coloredCell" style="text-align: center;">32</td><td class="coloredCell" style="text-align: center;">40</td><td style="text-align: center;"><span class="fontType">30</span></td></tr></tbody></table><h3 class="m-h3--wysiwyg">注文例</h3><div class="m-thumbnail"><div class="m-thumbnail__img has-border" data-autoheight="item"><img alt="丸形スキットブラケット　MRTB MRTB-N " src="//content.misumi-ec.com/image/upload/t_msmwm_wyg/v1/p/jp/product/wysiwyg/110100174560/110100174560_002_20230801115851.gif" /></div></div><h3 class="m-h3--wysiwyg">出荷日</h3><div class="m-thumbnail"><div class="m-thumbnail__img has-border" data-autoheight="item"><img alt="丸形スキットブラケット　MRTB MRTB-N " src="//content.misumi-ec.com/image/upload/t_msmwm_wyg/v1/p/jp/product/wysiwyg/110100174560/110100174560_003_20230801115851.gif" /></div></div>
