JST コネクタハウジング オス 2極 1列 XLシリーズ

・コンタクト数 = 2
・行数 = 1
・ジェンダー = オス
・取り付けタイプ = ケーブルマウント
・シリーズ = XL
・併用可能製品 = 取り外し可能な圧着電線対電線コネクタ
・ボディ向き = ストレート
・深さ = 18.7mm
・ハウジング材質 = ナイロン

UL, CSA, TUV. 基板用コネクタ XLハウジング. The XL connectors can be used for wire-to-wire or wire-to-board connections. Since all contacts are individually and surrounded by housing walls, and since the connector pitch is 5.0 mm （.197"）, the creep and space distances between the contacts are large enough to meet stringent safety requirements. The box-shaped contact is adaptable to a wide range of applications, from low voltage, low-current signal circuits to power supply circuits. Features ; Benefits. Reliable housing construction. Easy contact insertion. Box-shaped contact. Two kinds of connections
