<div class="pad_b15" style="display: flex; gap: 30px; align-items: flex-start;"><div><img alt="" src="//content.misumi-ec.com/image/upload/t_msmwm_wyg/v1/p/jp/product/wysiwyg/110300420120/110300420120_001_20230801115852.gif" /></div><div>■付属品<br />(MOR)<br />・端子金具（①②③）<br />・④ボルト・⑤ばね座金・⑥ナット（M5各2つ）<br />(MORS)<br />・固定金具（①）・端子ボックス（②③）<br />・④ボルト・⑤ばね座金・⑥ナット（M5各2つ）</div></div><div class="pad_b15" style="display: flex; gap: 30px; align-items: flex-start;"><div>(MOR)<br />D38・42.7用端子金具<br /><img alt="" src="//content.misumi-ec.com/image/upload/t_msmwm_wyg/v1/p/jp/product/wysiwyg/110300420120/110300420120_002_20230801115852.gif" /></div><div>(MORS)<br />D38・42.7用固定金具<br /><img alt="" src="//content.misumi-ec.com/image/upload/t_msmwm_wyg/v1/p/jp/product/wysiwyg/110300420120/110300420120_003_20230801115852.gif" /></div><div><br />フレーム取付参考図<br /><img alt="" src="//content.misumi-ec.com/image/upload/t_msmwm_wyg/v1/p/jp/product/wysiwyg/110300420120/110300420120_004_20230801115852.gif" /></div><div><br />フレーム取付参考図寸法<table border="2" cellspacing="0" rules="all"><tbody><tr><td align="center" class="headerCell">D</td><td align="center" class="headerCell">W1</td><td align="center" class="headerCell">W2</td><td align="center" class="headerCell">W3</td><td align="center" class="headerCell">P1</td></tr><tr><td align="center" class="bodyCell"><font class="fontType">38</font></td><td align="center" class="bodyCell" rowspan="2">12mm以上</td><td align="center" class="bodyCell" rowspan="2">22mm</td><td align="center" class="bodyCell" rowspan="2">19mm以上</td><td align="center" class="bodyCell" rowspan="2">34mm</td></tr><tr><td align="center" class="bodyCell"><font class="fontType">42.7</font></td></tr><tr><td align="center" class="bodyCell"><font class="fontType">57</font></td><td align="center" class="bodyCell">16mm以上</td><td align="center" class="bodyCell">47mm</td><td align="center" class="bodyCell">11mm以上</td><td align="center" class="bodyCell">35mm</td></tr></tbody></table></div></div><div class="pad_b15" style="display: flex; gap: 30px; align-items: flex-start;"><div>(MOR)<br />D57用端子金具<br /><img alt="" src="//content.misumi-ec.com/image/upload/t_msmwm_wyg/v1/p/jp/product/wysiwyg/110300420120/110300420120_005_20230801115852.gif" /></div><div>(MORS)<br />D38・42.7用端子ボックス（②端子金具＋③端子金具カバー）<br /><img alt="" src="//content.misumi-ec.com/image/upload/t_msmwm_wyg/v1/p/jp/product/wysiwyg/110300420120/110300420120_006_20230801115852.gif" /></div></div><div class="pad_b15"><span class="fontNote">[ ! ]</span>使用温度　0～40℃（湿度15～85％）</div><div class="pad_b15"><table cellspacing="0" rules="all"><tbody><tr><td align="center" class="headerCell" rowspan="2">Type</td><td align="center" class="headerCell" rowspan="2">D</td><td align="center" class="headerCell" colspan="2">ローラ</td><td align="center" class="headerCell" colspan="2">①固定金具</td><td align="center" class="headerCell">②端子金具</td><td align="center" class="headerCell">③端子金具カバー</td></tr><tr><td align="center" class="headerCell">[ M ]材質</td><td align="center" class="headerCell">[ S ]表面処理</td><td align="center" class="headerCell">[ M ]材質</td><td align="center" class="headerCell">[ S ]表面処理</td><td align="center" class="headerCell">[ M ]材質</td><td align="center" class="headerCell">[ M ]材質</td></tr><tr><td align="center" class="bodyCell" rowspan="3">(標準)<br /><font class="fontType">MOR</font></td><td align="center" class="bodyCell"><font class="fontType">38</font></td><td align="center" class="bodyCell" rowspan="3">STKM12</td><td align="center" class="bodyCell" rowspan="3">三価クロメート</td><td align="center" class="bodyCell" rowspan="3">SPHC</td><td align="center" class="bodyCell" rowspan="3">三価クロメート</td><td align="center" class="bodyCell" rowspan="2">PA6</td><td align="center" class="bodyCell" rowspan="3">ABS樹脂</td></tr><tr><td align="center" class="bodyCell"><font class="fontType">42.7</font></td></tr><tr><td align="center" class="bodyCell"><font class="fontType">57</font></td><td align="center" class="bodyCell">PBT</td></tr><tr><td align="center" class="bodyCell" rowspan="2">(防水)<br /><font class="fontType">MORS</font></td><td align="center" class="bodyCell"><font class="fontType">38</font></td><td align="center" class="bodyCell" rowspan="2">SUS304</td><td align="center" class="bodyCell" rowspan="2">&minus;</td><td align="center" class="bodyCell" rowspan="2">SUS304</td><td align="center" class="bodyCell" rowspan="2">&minus;</td><td align="center" class="bodyCell" rowspan="2">PBT</td><td align="center" class="bodyCell" rowspan="2">PBT</td></tr><tr><td align="center" class="bodyCell"><font class="fontType">42.7</font></td></tr></tbody></table></div>
